OLYMPUS 奥林巴斯 DP28 数码相机
Reliable Data from Images You Can Trust
The DP28 digital microscope camera for industrial inspection combines powerful features, precise color accuracy, and up to 4K resolution across a wide field of view to provide high-resolution images of your inspection samples that are free from artifacts. Make your inspections fast and efficient with images that are sharp and clear, even when moving the stage.
Powerful Imaging Features
High-quality images from dim samples: During polarization or fluorescence observation, High Contrast mode enables easier image acquisition with a high signal-to-noise ratio
Reliable long-exposure imaging: The Fast Live function provides a consistently high frame rate, so your image remains smooth when scanning samples, even under low light conditions
Know whether your measurement area is in focus: The Focus Peaking function shows a map of the sample with the in-focus areas in color and the out-of-focus areas in grayscale
Smart Image Technology: Olympus smart image averaging (OSIA) suppresses noise and eliminates artifacts while maintaining a fast frame rate.
DP28 specifications
| C-mount |
| Color CMOS Camera |
| 1 in. Color CMOS |
|---|
| 8.9 megapixel |
|---|
| Progressive scanning |
|---|
| Global shutter |
| 4104 x 2174 Full Resolution |
Up to 64fps Full HD
Up to 32fps Full Resolution |
Auto：27 μs to 15 s
Manual：27 μs to 15 s |
| USB3.1 Type-C® |
| 76.7（W） × 70.1（D） × 37.3（H）mm |
| 380g |
Display output: 2 × HDMI
I/F: 4 × USB3.1 Gen1*1
Audio: Mic input (monaural) , phone jack
Wired LAN: 2 × LAN (1000BASE-T/100BASE-TX/ 10BASE-T)
Serial port: RS-232C |
Scale bar supported
Document name, total magnification, objective magnification, zoom magnification
10 % to 1600 % |
| Measurement function count, distance between 2 points, polyline, 3-point circle, rectangle, 3-point angle, 4-point angle, perpendicular, area and perimeter of polygon, distance between 2 centers, ruler |
*1 USB 3.1 Gen1 is compatible with USB 3.0
*2 The DP28-AOU configuration only
